PGY-SPMI Electrical Validation & Protocol Analysis Software

SPMI Electrical Validation and Protocol Decode Software offers electrical measurements compliance testing as specified in SPMI specification. PGY-SPMI Electrical validation and Protocol Decode software runs in Tektronix Oscilloscope and provides electrical measurements and protocol decoding at the click of a button.

PGY-SPMI Electrical Validation & Protocol Analysis Software

Features

The SPMI supports the following features:

  • It’s using oscilloscope live channel data or stored SPMI signals (wfm (default), h5, trc format ( with option)).
  • Links the content to the electrical signal in the oscilloscope for easy understanding of the electrical characteristics of the protocol.
  • Displays the decoded data in SPMI frame format
  • Error checks for parity bits of command and data.
  • Flexibility to view Slave ID in Symbol or Hex value.
  • Flexibility to view decoded data in hex, binary, Decimal, or octal format.
  • Long duration data decode support to capture more number of SPMI protocol transactions.
  • Search capabilities to locate protocol events.
  • Filter capabilities to view information of Interest.
  • Documentation by exporting data in CSV and TXT file format along with PDF Report Generation.
  • API Support with Python.
