PGY-RFFE-EX-PD Protocol Exerciser and Analyzer

RFFE Protocol Analyzer(PGY-RFFE-EX-PD) is the Protocol Analyzer with multiple features to capture and debug communication between host and design under test. The RF Front-end control interface (RFFE) Serial bus interface is emerging as a chosen for controlling RF frond end devices. There are variety of front end devices such as Power Amplifiers (PA), Low-Nose Amplifiers (LNA), filters, switches, power management modules, antenna tuners. It is widely used in mobile devices.

PGY-RFFE-EX-PD Protocol Exerciser and Analyzer

PGY-RFFE-EX-PD is the leading instrument that enables the design and test engineers to test the RFFE interface for its specifications by configuring PGY-RFFE-EX-PD as master/slave, generating RFFE traffic with error injection capability, amplitude variation and decoding RFFE Protocol decode packets.

The product features are as follows:

  • Supports RFFE2.0/2.1 Specification
  • Ability to configure it as Master or Slave
  • Generate different RFFE at full speed and half of full frequency speed
  • Error Injection such as parity errors and ACK/NACK errors
  • Variable RFFE data speeds
  • Simultaneously generate RFFE traffic and Protocol decode of the Bus
  • Timing diagram of Protocol decoded bus
  • Listing view of Protocol activity
  • Error Analysis in Protocol Decode
  • Ability to write exerciser script to combine multiple data frame generation at different data speeds
  • USB2/3 host computer interface
  • Flexibility to upgrade to the unit for evolving RFFE Specification

Multi-domain View

Multi domain View provides the complete view of RFFE Protocol activity in single GUI. User can easily setup the analyzer to generate RFFE traffic using a GUI or script. User can set different trigger conditions from the setup menu to capture Protocol activity at specific event and decode the protocol transactions between Master and Slave. The decoded results can be viewed in timing diagram and Protocol listing window with autocorrelation. This comprehensive view of information makes it industry best, offering an easy to use solution to debug the RFFE protocol activity.


PGY-RFFE-EX-PD supports RFFE traffic generation using GUI and Script. User can generate simple traffic generation using the GUI to test the DUT. Script based GUI provides flexibility to emulate the complete expected traffic in real world including error injections. In this sample script user can generate RFFE traffic as below.

  • SET Dynamic Address using slave static
  • SETMWL with Data Parity Error
  • GETMWL with Command Parity Error
  • ENTHDR0 DDR mode with CRC Error

Timing Diagram and Protocol Listing View

Timing view provides the plot of SCLK and SDATA signals with bus diagram. Overlaying of Protocol bits on the digital timing waveform will help easy debugging of Protocol decoded data. Cursor and Zoom features will make it convenient to analyze Protocol in timing diagram for any timing errors.

Protocol window provides the decoded packet information in each state and all packet details. Selected frame in Protocol listing window will be auto-correlated in timing view to view the timing information of the packet.

Powerful Trigger Capabilities

PGY-RFFE-EX-PD supports Auto, simple and advanced trigger capabilities. Analyzer can trigger on any of the Protocol packets such as Ext. Reg. Write, Ext. Reg, read and so forth message. Advanced Trigger provides the flexibility to monitor multiple trigger conditions and can set multiple state trigger machines.

PGY-RFFE-EX-PD Specification

Configurable 1 Master+ Four Slaves OR
RFFE Traffic generation Custom RFFE Traffic Generation
Simulate real world network traffic
SCLK Frequency 400KHz to 13.5MHz
Voltage drive level 1 V to 3.3V at steps of 100mV
SCL Duty Cycle variation User Define
SCL and SDA Delay User Define
Delay between two messages User Define
Error Injection Parity Error Injection


Protocol Analysis
Supports RFFE 2.0/2.1 Protocol Decode
Protocol views Timing Diagram view Protocol Listing View
Protocol Trigger Auto (Trigger on Any Packet) Simple
(Trigger on any user defined RFFE packet)
Advanced (Multistate and Multilevel Trigger
with Timer Capability)
Capture Duration Continious streaming Protocl data
to Host HDD/SSD
Protocol Error Report PARITY
Host Coonectivity USB3.0/2.0 interface

Ordering Information
PGY-RFFE-EX-PD RFFE Protocol Exerciser and Analyzer


  • USB3.0 cable
  • PGY-RFFE-EX-PD Software in CD
  • 12V DC adopter
  • Flying lead probe cable with female connector to connect to DUT
